Hyundai 9 Series diesel forklifts bring you all the power you need to handle your toughest applications. Beyond pure power is a highly efficient machine that maximizes operator comfort and productivity while simplifying maintenance. The result is more loads moved per shift with less effort, expense, and downtime.
LOAD CAPACITY
8,000-11,000 lbs.TIRE TYPE
PneumaticENGINE
Cummins Diesel
LOW EMISSION CUMMINS DIESEL
This powerful, turbocharged engine meets all EPA Tier 4 and EU Stage IV emissions. It features a high-pressure common rail fuel system for outstanding performance with low noise and vibration.
SUPERIOR GRADEABILITY
Thanks to its powerful engine, the 9 Series offers improved gradeability, better acceleration, and faster travel speeds, up to 16.5 mph, over the toughest terrain and steepest slopes.
RUGGED DRIVE AXLE
Designed for years of reliable service, the drive axle includes an innovative ring gear that reduces noise and wet disc brakes for more consistent braking with reduced maintenance.
INFORMATION RICH LCD CLUSTER
LCD cluster consolidates important equipment information, real-time data, onboard diagnostics, data logging, safety features, maintenance tracking and more for complete system control.
FULL SUSPENSION GRAMMER™ SEAT
Comfortable seat adjusts to the operator’s body weight, with adjustable armrests and lumbar support to reduce strain and fatigue, all while enhancing productivity and safety.
SPACIOUS OPERATOR CABIN
The comfortable cab provides more space for operators with a wider field of view. It includes an adjustable steering wheel, and optimized pedal position for precise handling with less effort.
EASY SERVICE ACCESS
An easy lifting hood reveals a large workspace that provides ready access to key components and consumables for fast, efficient maintenance and reduced downtime.
ENGINE DIAGNOSTICS
Highly visible in the digital cluster, operators have ready access to engine status and issues all available without the need for a separate diagnostic tool. Service intervals are also easily tracked.
PROTECTED COMPONENTS
To assure greater reliability, ease of maintenance, and more uptime, key components are carefully positioned and protected, including water- and dust-proof fuse and relay boxes.
OPERATOR PRESENCE SENSING SYSTEM
To prevent accidents and protect workers, this system requires the operator be present, in the seat, to have the use of the travel and hydraulic functions, including tilting, lifting, and lowering.
OUTSTANDING VISIBILITY
The 9 Series features an optimized lift cylinder arrangement that provides a wide view of the work environment for greater safety for the operator and others working in your facilities.
INCLINATION WARNING SYSTEM
To improve productivity and safety especially on uneven terrains, the forklift inclination warning system monitors and visibly indicates forward/backward, right/left degree of the machine.
| LOAD CAPACITY | 8,000-11,000 lbs. |
| TRAVEL SPEED (UNLOADED) | 15.9-16.5 mph |
| ENGINE MODEL | Cummins QSF3.8 |
| POWER | 101 HP/2,200 RPM |
| LENGTH TO FACE OF FORKS | 127-130 in. |
| OVERHEAD GUARD HEIGHT | 92.13 in. |
| OVERALL WIDTH | 54 in. Single 68.5 in Double |
| TURNING RADIUS | 116-118.5 in. |
