When it comes to quickly, efficiently, and safely picking orders from even the highest racks, the 13 BOP-9 stands tall. Offering superior maneuverability to navigate tight aisles, it delivers innovative features and design advantages that speed work while assuring maximum operator comfort and productivity.
LOAD CAPACITY
3,000 lbs.TIRE TYPE
PolyurethaneBATTERY TYPE
24V-36V Lead-Acid
EPS & AUTOCENTERING
The 13 BOP-9 is a model of precise handling with smooth operating power steering and a system that automatically centers the wheel when the key switch is powered on.
OPTIONAL HEIGHT INDICATOR
With up to 50 presets available, operators merely need to select the desired height on the cluster and the platform will automatically stop once reached increasing productivity.
OPTIONAL WIRE GUIDANCE
Steering is automatically controlled by an electric signal sent from discreet wiring the floor for greater operator control, enhance productivity, and more precise handling.
MULTIFUNCTION LCD CLUSTER
Advanced monitor consolidates and displays essential equipment information, real time data, onboard, diagnostics, data logging, safety features, maintenance tracking and more.
MULTIFUNCTION CONTROL HANDLE
With this unique system, operators can control the direction of travel, lifting and lowering the platform, and the horn, with just one hand, making order picking faster and easier.
ADJUSTABLE CONTROL PANEL
The entire operator compartment is designed for maximum operator comfort and control, including the control panel that offers 3” of height control for more precise handling.
EASY COMPONENT ACCESS
The 13 BOP-9 has been designed to minimize downtime and simplify maintenance. For example, two-piece steel doors open 180O to allow easy access to all major components.
ZAPI DUAL MICRO-CONTROLLER
This advanced control monitors dual signals to detect any possible faults to speed servicing. It features onboard diagnostics and protection from overloads.
RELIABLE AC MOTOR
The highly efficient AC motor not only delivers superior performance with low noise levels but features a temperature sensor to help prevent overheating and extend motor life.
CURVE CONTROL
This key feature reduces the risk of the operator exceeding the safe speed of the forklift when making a turn by controlling the travel speed and acceleration of the unit.
REAR SAFETY GATE
This optional feature can be added between the platform and the fork to prevent any accidents. Operators are further protected by a standard toe board added to the bottom of the safety bar.
STRONG OVERHEAD GUARD
Exceeding CEE and ANSI regulations, the overhead guard offers great protection with excellent visibility. It includes work lamps and cooling fans for operator convenience and comfort.
| LOAD CAPACITY | 3,000 lbs. |
| TRAVEL SPEED (UNLOADED) | 7.5 mph |
| VOLTAGE | 24-36V |
| LENGTH TO FACE OF FORKS | 76 in. |
| OVERHEAD GUARD HEIGHT | 87.4 in. |
| OVERALL WIDTH | 40.2-49.2 in. |
| TURNING RADIUS | 71.6 in. |
